BƠM DẦU ACTWELL MODEL 80
* Đặc điểm:
Sản phẩm dùng chuyên dụng cho bơm hút dầu bôi trơn từ thùng phuy dung tích 200 lít,bơm hoạt động với nguồn khí nén đảm bảo an toàn tuyệt đối trong vận hành và sử dụng
Được sản xuất dựa trên cơ sở của Bơm mỡ bôi trơn, Bơm dầu Actwell Model 80 hoạt động với áp lực đầu ra lớn phù hợp bôi trơn cho các thiết bị cỡ lớn
* Thông số kỹ thuật:
Model. No |
Container size |
Pressure ratio |
Delivery rate |
|
F80 |
200 lit |
5:1 |
41 l/min |
- F series 5:1 oil pump with 3" effective dia. air motor, 2-3/4" stroke, 3/8"PT-19(F) air inlet, 3/8"PT-19(F) fluid outlet
- 40054 Air Connector, 540053 Fluid Coupler and 20180906 Bung Opening included
• w/20180906 Bung Opening
•In free delivery (no hose, gun), at 6 kg/cm²
•Using motor oil SAE 30 at room temperature 25°C
|
J80 |
200 lit |
9:1 |
19 l/min |
- J series 9:1 oil pump with 3" effective dia. air motor, 2-3/4" stroke, 3/8"PT-19(F) air inlet, 3/8"PT-19(F) fluid outlet
- 40054 Air Connector, 940053 Fluid Coupler and 40980906Bung Opening included
• w/40980906 Bung Opening
•In free delivery (no hose, gun), at 6 kg/cm²
•Using motor oil SAE 30 at room temperature 25°C
|
L80 |
200 lit |
15:1 |
11 l/min |
- L series 15:1 oil pump with 3" effective dia. air motor, 2-3/4" stroke, 3/8"PT-19(F) air inlet, 3/8PT-19(F)fluid outlet
- 40054 Air Connector, 940053 Fluid Coupler and 40980906Bung Opening included
• w/40980906 Bung Opening
•In free delivery (no hose, gun), at 6 kg/cm²
•Using motor oil SAE 30 at room temperature 25°C
|
Xuất xứ: Hãng Bơm mỡ Actwell- Taiwan
Bảo hành: 12 tháng
BƠM MỠ ACTWELL- PHÂN PHỐI ĐỘC QUYỀN BỞI INVESCO VIỆT NAM
